NQGX-30-150型口服液、糖浆灌装轧盖机

产品详情Product Details

用途与简介/Brief introduction:

本机是在引进和吸收国外先进技术的基础上,由我公司自主研发的一款专业针对口服液和糖浆的灌装、上塞、旋(轧)盖机。本机采用日本全进口高精度封闭式凸轮分度工位器,精度高,运行可靠,使用寿命长。该分度器结构简单,长期使用无需维修。

本机主要适用于各种口服液及糖浆液体的灌装、压塞及旋(轧)盖,广泛用于食品、制药、化工行业及科研领域。完全符合国家GMP要求。

NFGX-30/100 Automatic Oral&sSyrup Filling&rotation (rolling) machine is built in the absorption of foreign advanced tecnology, based on independently developed by the company ,It is the domestic leading level.

This machine is suitable for oral and syrup liquid filling&capping. Widely used in food, pharmaceutical, chemical industries and scientific research.Full compliance with the GMP requirements.



特点/Characteristic:

◆人机界面设定、操作直观方便、PLC控制,装量*。

Human-machine interface settings, an easy and intuitive, PLC control.

◆变频控制、生产速度任意调节、自动计数。

Frequency control, the production rate be adjusted automatically count.

◆自动停机功能,无瓶不灌装。

No bottle no filling.

◆高精度凸轮分度计控制,定位*。

High-precision cam meter control, precise positioning

◆采用SUS304及316L不锈钢制造,完全符合GMP要求。

SUS304 and 316L stainless steel, full compliance with GMP requirements.


技术参数/ technical parameters:

装量范围Filling volume

30-150ML

装量误差loading error

≤ ±1%

旋(轧)盖合格率Rotation (rolling) Cover pass rate

≥99%

生产能力 Production capacity

30-60瓶/分 钟  低速 70-100瓶/分 钟     高速

30-60 bottles / min  70-100 bottles / min

电源Power

380V/50Hz

功率Power

2.0 kw

机器净重Net weight

600 kg

外形尺寸Dimension

2000*1000*1500mm
